6(4+2) steats Lithium Battery Powered Lifted Electric Off Road Golf Cart, 72V AC system, 5KW/7.5KW AC motor, 100Ah Lithium Battery, front MacPherson Independent suspension, front disc brake, LED lights, digital meter, 14′ aluminum rim, sports steering wheel…
2-Seat and 4-Seat Options Available
Versatile Seating and Power Options: This 6-seat (4+2) Electric Off-Road Golf Cart offers flexible seating arrangements with 2-seat and 4-seat options available, catering to different group sizes. It features a robust 72V AC system and a choice between a 5KW or 7.5KW AC motor, powered by a 100Ah lithium battery, providing ample power and extended range for all your outdoor adventures.
Advanced Riding Comfort and Safety: Equipped with a front MacPherson Independent suspension and front disc brakes, the golf cart ensures a smooth and safe ride on rough terrains. The independent suspension system offers superior handling and comfort, while the disc brakes provide reliable stopping power, enhancing overall safety.
High-Quality Features and Build: This golf cart is designed with premium components including LED lights for improved visibility, a digital meter for real-time performance tracking, 14-inch aluminum rims for durability and style, and a sports steering wheel for a comfortable and engaging driving experience. These features combine functionality with luxury, making it an ideal choice for both utility and leisure activities.
The 4+2 Seats Hunting Buggy offers exceptional versatility and performance for outdoor adventures. Its strong electric motor guarantees environmentally friendly, noiseless operation, making it perfect for hunting without upsetting wildlife. It offers plenty of comfortable seating for up to six people. The buggy can easily traverse tough terrain thanks to its strong off-road tires and considerable ground clearance. It ensures exceptional visibility in low light thanks to energy-efficient LED lighting. The roomy cargo area is ideal for storing hunting supplies and games, and the strong, reinforced frame increases durability and safety. Enjoy exceptional dependability and performance with this cutting-edge hunting buggy.
| Quick Details 4+2 Seats Hunting Buggy | |||
|---|---|---|---|
|
Quick Details
System Voltage |
72V
|
Passenger Capacity
|
6
|
|
Motor Power (Rated)
|
5KW/7.5KW
|
Range (Loaded)*
|
>100km
|
|
Motor Power (Maximum)
|
10KW/15KW
|
Max. speed
|
32km/h
|
|
Motor Type
|
AC
|
Gradeability (%)
|
25%
|
|
Battery Type
|
Lithium Battery
|
Min. turning radius (m)
|
3.5m
|
|
Battery Voltage/Capacity
|
72V/100Ah
|
Max. loading weight
|
620kgs
|
|
Controller
|
EMPOWER/CURTIS
|
Overall Dimensions
|
2920X1180X1890mm
|
The Range Is Based On The Testing Conditions Of an Even Speed Of 20km/H, Flat And Straight Paved Road, Temperature Of 25 Celsus Degrees, Wind Speed Less Than 5m/S. The range Will Vary Depending On Temperature, Grade, Payload, And Driving Style.
| Body & Frame | |||
|---|---|---|---|
|
Frame
|
Welded steel framework with anti-rust treatment of acid washing + phosphating + electro-coating
|
●
|
|
|
Body
|
PP plastic front body + PP plastic rear body, with painting
|
●
|
|
|
Roof
|
Injected plastic, gel coated
|
●
|
|
|
Front windshield
|
Foldable organic plastic windshield
|
●
|
|
|
Laminated glass windshield
|
○
|
||
|
Laminated glass windshield with wiper
|
○
|
||
|
Roof Supports
|
Plastic
|
●
|
|
|
Sweater Basket
|
Plastic
|
●
|
|
|
Backrest and cushion
|
Reborn sponge + artificial leather + plastic armrest
|
●
|
|
|
Backrest Cover
|
Plastic, in black color
|
●
|
|
|
Wood finish
|
○
|
||
|
Floor
|
Galvanized Steel Sheet + anti-slip ruber mat
|
●
|
|
|
Dashboard
|
Plastic, injected, in black
|
●
|
|
|
Wood finish
|
○
|
||
|
Carbon fiber
|
○
|
||
|
Steering Wheel
|
Black artificial leather covered, with score card
|
●
|
|
|
Wood finish
|
○
|
||
|
Carbon fiber
|
○
|
||
|
Side trim
|
Aluminum
|
●
|
|
|
Side rear view mirror
|
2pcs, foldable
|
●
|
|
|
Central rear view mirror
|
\
|
○
|
|
|
Glove box door & lock
|
Plastic, black or wood finish
|
○
|
|
|
Seatbelt
|
2-point retractable seatbelt
|
○
|
|
|
Enclosure
|
Transparent PVC + Canvas, with two sides zipper
|
○
|
|
| Electric System | |||
|---|---|---|---|
|
Lighting System &Horn
|
2 headlights, 2 front turning signals, 2 LED taillight (each combined 1 brake light with 1 turning signal), electric horn
|
●
|
|
|
DC/DC converter
|
20A, 72V/12V
|
●
|
|
|
Reverse Buzzer
|
Electric, 12V
|
●
|
|
|
Charger
|
Intelligent, input 110V-240V~50Hz-60Hz, output 72V/18A
|
●
|
|
|
Cooler
|
12V/6L
|
○
|
|
|
Digital Meter
|
speed, mileage, headlight indicator, emergency light indicator, turn signal indicator, reverse indicator
|
○
|
|
|
Hour meter
|
\
|
○
|
|
|
Emergency power-off button
|
To cut the main power
|
○
|
|
|
12V accessory plug
|
\
|
○
|
|
|
USB interface
|
\
|
○
|
|
| Steering system, brake system and suspension system | |||
|---|---|---|---|
|
Steering system
|
Single-stage rack and pinion steering system, with automatic rocker compensating function
|
●
|
|
|
Brake System
|
4 wheel dics hydraulic brake
|
●
|
|
|
Accelerator
|
Stepless speed change, resistor type
|
●
|
|
|
Suspension system
|
Front independent suspension and rear plate spring + cylinder hydraulic shock absorber
|
●
|
|
|
Driving mode
|
Rear axle two-stage deceleration, motor direct driving, rear wheel drive
|
●
|
|
|
Rear axle
|
Integrated, Gear ratio12.49:1
|
●
|
|
|
Wheel & Tyre
|
14’Alumimum wheel
|
●
|
|
‘●’ Means Standard Configuration; ‘○’ Means Optional Configuration
| Parameter and Configuration | RG142 | |
| Dimension：L*W*H | 3670mm*1390mm*2030mm | |
| Technical Parameters | Rated Passenger Capacity | 6 |
| Driving system | 2WD | |
| Maximum Speed | U.S. 25 miles/h (Europe 30 km/h) | |
| Braking Distance | ≤4m | |
| Wheelbase | 2400mm | |
| Front and Rear Track Width | 925/1000 | |
| Minimum Ground Clearance | 170 | |
| Maximum Climbing Gradient | 30% | |
| Minimum Turning Radius | 6m | |
| Curb Weight(including lithium battery) | 580kg | |
| Driving Range | ≥50 miles (on flat roads) | |
| Electric System | Controller | Yingboer48V-400A(optional:Curtis Toyota ) |
| Lead-Acid Battery | 48V 150AH | |
| Lithium iron phosphate | 48V 150AH(Optional)60V 150AH | |
| Electric Motor | full closed-loop control AC asynchronous motor,33V5kW | |
| Charger | Charger: U.S. 48V 13A/110V, Europe 48V 25A/220V (Charging time: 8-10 hours) | |
| DC Converter | Non-isolated DC Converter 48V/12V-300W | |
| Display Screen | 10.1-inch LCD IP66 waterproof multimedia combination instrument, with radio, MP5, bluetooth music, bluetooth phone, vehicle diagnostic function | |
| Body Configuration | Front Windshield | DOT-certified anti-rollover acrylic glass Optional: DOT-certified tempered glass + wiper |
| Floor | Sandblasted aluminum alloy non-slip floor | |
| Body Frame | Adopts a lightweight, high-strength trapezoidal frame design, with electrophoretic coating on the surface, | |
| Steering System | Bidirectional rack-and-pinion steering system with automatic gap compensation | |
| Brake System | Dual-circuit four-wheel hydraulic brakes, four-wheel disc brakes + electronic parking brake | |
| Front Axle and Suspension | Double wishbone independent suspension, coil springs + hydraulic shock absorber | |
| Rear Axle and Suspension | Integral rear axle with a gear ratio of 12.3:1, C-type frame trailing arm+coil spring shock absorbers+simple hydraulic shock absorbers+and stabilizer bar | |
| Tire Diameter | Tires: 23-10.5-12, 12-inch aluminum alloy wheels | |
